| NO. | Brand | Compatible P/N | Transceiver Type |
| 1 | Cisco | QSFP56-200G-AOC100M | |
| 2 | Arista Networks | A-Q200-Q200-100M | |
| 3 | HPE Aruba | QSFP56-200G-AOC100M | |
| 4 | Intel | QSFP56-200G-AOC100M | |
| 5 | NVIDIA/Mellanox | MFS1S00-V100E | |
| 6 | H3C | QSFP56-200G-AOC100M |
Key Technical Specifications
| Cisco Compatible |
QSFP56-200G-AOC100M
|
Vendor Name | HYTOPTODEVICE |
| Connector | QSFP56 to QSFP56 | Max Data Rate | 200Gbps |
| Operating Wavelength | 850nm | Fiber Cable | OM4 MMF |
| Cable Length | 100m (328ft) | Power Consumption | ≤4.5W |
| Host Required | FEC | Operation Temperature | 0~ 70 °C (32 to 158°F) |
| Minimum Bend Radius | 30mm | Protocols | IEEE 802.3, QSFP56 MSA, SFF-8665, SFF-8636 |
| Application |
200G-SR4 Ethernet
|
Warranty | 5 Years |
Usage Guidelines & Best Practices
For detailed operation instructions, please refer to the User Guide.
Full Compatibility List & Supported Devices
Built on universal MSA open standards, this product from our cisco 200g qsfp56 active optical cable supplier portfolio supports mixed-vendor networking hardware. It interoperates seamlessly with Arista, NVIDIA, H3C, Juniper, Dell and other mainstream brands, suitable for mixed-brand fabric deployment and HPC cluster expansion.






Q1: Can QSFP56 AOC transceivers plug into QSFP-DD ports and run high-speed links normally? A: No. QSFP56 and QSFP-DD differ in physical dimensions and pin layout. This Cisco compatible 200g qsfp56 active optical cable aoc manufacturer product cannot fit QSFP-DD slots, a key reminder for operators upgrading multi-form-factor fabrics.
Q2: Is it feasible to split this direct 200G AOC into two independent 100G signal channels? A: No. This is a non-breakout straight AOC designed for single-channel transmission. It transmits one unified 200G PAM4 stream and cannot be divided into dual 100G links. Contact HYTOPTODEVICE if you need breakout AOC solutions for your sourcing project.
Q3: Does this AOC tend to trigger unknown module notification alerts on Cisco switching and adapter hardware? A: It will not trigger alerts with our custom EEPROM programming service. HYTOPTODEVICE calibrates module profile data to match Cisco platforms for this 200g qsfp56 active optical cable aoc manufacturer product, simplifying large-scale rack rollout.
Q4: Is this Cisco compatible 200G QSFP56 AOC restricted to only Ethernet networking? A: No. This 20m AOC follows MSA PAM4 specifications, supporting both Ethernet and InfiniBand HDR100 workloads, which makes it versatile for dual-use data center and HPC environments.
Q5: Can this 200G QSFP56 AOC establish stable high-speed links between multi-vendor network and HPC hardware? A: Yes. Built on MSA open standards, this 200g qsfp56 active optical cable aoc manufacturer cable delivers reliable cross-vendor interoperability to connect Cisco, Arista, NVIDIA, Dell and other compatible devices for mixed-brand fabric construction.
Q6: How will the latency of QSFP56 AOC compare with DAC and standalone optical transceivers for high-speed compute networks? A: AOC latency is slightly higher than DAC, approximately 5–10 ns. This minor opto-electrical conversion delay barely affects Ethernet leaf-spine and InfiniBand HPC workloads, while this 20m AOC supports longer transmission distances than copper DAC alternatives.
Q7: What is the power draw on each end of this 200G AOC, and how does it compare with competing high-speed AOC products? A: Power consumption is 4.5W per end. Our HYTOPTODEVICE 200G QSFP56 AOC adopts optimized circuit design, delivering lower power consumption than many competing AOCs and easing thermal pressure in dense server and GPU racks.
Q8: Will electromagnetic interference from nearby power lines disrupt the high-speed signal carried by this AOC? A: No. Data transmits via light through glass fiber rather than copper conductors. This Cisco compatible AOC is fully EMI immune, suitable for routing near power supplies in high-density, electrically noisy rack environments.
Q9: What bandwidth capacity can each individual lane support on this 200G QSFP56 active optical cable? A: Each lane supports 50Gbps PAM4. Four parallel lanes combine to reach the full 200G aggregate bandwidth of this 200g qsfp56 active optical cable aoc manufacturer cable for compute and storage interconnections.
Q10: Will varying OM4 AOC cable lengths create obvious signal attenuation gaps on 200G PAM4 links? A: Optical loss rises gently with length within OM4’s rated working range. Attenuation stays within acceptable link budget limits; our 20m factory stock model maintains clean signals for long cross-rack uplinks.
Q11: Why should data center and HPC buyers choose factory AOC instead of pairing two separate 200G transceivers plus fiber patch cords? A: Factory pre-terminated AOC reduces installation steps and potential failure points. For short-distance transmission runs below 30 meters, the AOC solution is highly recommended, and our HYTOPTODEVICE 200G QSFP56 AOC is a cost-effective manufacturer option for bulk rollout.
Q12: If one transceiver end is damaged, can I replace only the faulty head instead of changing the whole AOC? A: No. The AOC is a sealed integrated optical assembly. When one transceiver end fails, the entire cable needs replacement. HYTOPTODEVICE supports stable stock and fast lead times for replacement orders of this 200g qsfp56 active optical cable aoc manufacturer cable.
Q13: What bending limit should installers follow when routing this 200G AOC inside compact server and GPU racks? A: The minimum bend radius is 30mm. Bending tighter than this limit will introduce extra optical attenuation. Installers must comply with this requirement during cabling for this 20m Cisco compatible AOC.
Q14: Can the pull-tab latch withstand frequent hot plugging during regular data center and HPC maintenance? A: It is built for heavy use. The pull tab is reinforced for repeated plug-and-unplug cycles. Our 200g qsfp56 active optical cable aoc manufacturer cable uses sturdy latch tabs to stand regular hot swapping during cluster maintenance.
Q15: How does the weight of a long 200G AOC compare with twinax DAC cables of the same length for rack cabling layouts? A: AOC is much lighter than equivalent twinax DAC. Optical fiber has far lower density than copper, so even longer AOCs reduce port load and simplify cable management in tall, densely packed server racks.
Packaging & Custom OEM Solutions
ESD Protection & Fast Shipping: Every transceiver is sealed in an ESD-safe bag and ready for same-day dispatch from stock.
Custom OEM & Branding: We provide logo printing, private labeling, and custom packaging to help distributors and integrators build their brand—no factory investment required.

Why Network Engineers Choose HYTOPTODEVICE
HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.
“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia
Quality Certification & Compliance
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
ISO 9001: Certified quality management and production consistency.
CE & FCC: Fully compliant for seamless Global Market Access.
RoHS: Committed to environmental responsibility and hazardous material control.
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.
